Pilot - (MS)
Ride the Future: Silent, Smooth, Electric
Pilot – (MS)
Introducing the PILOT – a dependable electric 3-wheeler built for urban and rural mobility. This model combines strength, efficiency, and safety, making it ideal for daily commutes, passenger transport, or light cargo.
Colors Availablity
Tailored Made
Power & Precision
Detailed
Specifications
| Motor | BLDC 1000W/1250W |
| Controller | 50A Capacity |
| Speed | 25 KM/H (Economy Mode) |
| Charger | 18AMP/25AMP |
| Range/Charge | 90–100 km |
| Charging Time | 4–8 Hours |
| Gross Vehicle Weight | 730 kg |
| Front Suspension | 43MM Telescopic Hydraulic |
| Rear Suspension | Leaf Spring with Spring Shocker |
| Brake System | Drum Brakes (Front & Rear) |
| Wheel Base | 2110 mm |
| Ground Clearance | 430 mm |
| Dimensions (LxWxH) | (2770 x 1000 x 1695) MM |
| Key Feature | Central Locking & Fog Lights |
| Head Light | 12V Tube |
| Tyre | Front - 3.75 - 12 / Rear - 3.75 - 12 |
| Back Light | Unique Design with LED |
| Speedometer | Digital |
| Battery | Lead Acid / Lithium Ion |
| Wheel | Stylish Aluminium Alloy Wheel |
| Seats Capacity | 4+1 Passenger |
Motor
Motor Type: BLDC Hub Motor (1000W / 1250W)
Drive Type: Hub Motor
Controller: 60V / 30A – 50A
Drive Type: Hub Motor
Controller: 60V / 30A – 50A
Battery
Battery Type: Lead Acid / Lithium-ion
Voltage / Power: 60V / 1000W
Charging Time: 3–8 hours
Charger Capacity: 18AMP / 25AMP
Voltage / Power: 60V / 1000W
Charging Time: 3–8 hours
Charger Capacity: 18AMP / 25AMP
Performance
Top Speed: 25 KM/H (Economy Mode)
Range per Charge: 80–100 km
Range per Charge: 80–100 km
Chassis
Front: Disc / Drum
Rear: Drum
Front: 3.10 or 3.75 – 12 Tubeless
Rear: 3.75 – 12
Rear: Drum
Front: 3.10 or 3.75 – 12 Tubeless
Rear: 3.75 – 12
Dimensions
L × W × H: 2750 × 990 × 1790 MM
Gross Vehicle Weight: 584 Kgs
Seating Capacity: 4+1 Passengers
Loading Capacity: 150 Kg
Gross Vehicle Weight: 584 Kgs
Seating Capacity: 4+1 Passengers
Loading Capacity: 150 Kg
