Pilot Auto SS
Ride the Future: Silent, Smooth, Electric
Pilot – Auto (SS)
Introducing the PILOT – a dependable electric 3-wheeler built for urban and rural mobility. This model combines strength, efficiency, and safety, making it ideal for daily commutes, passenger transport, or light cargo.
Colors Availablity
Tailored Made
Power & Precision
Detailed
Specifications
| Motor | BLDC 1000W/1250W |
| Controller | 50A Capacity |
| Speed | 25 KM/H (Economy Mode) |
| Charger Specifications | 18AMP/25AMP |
| Range/Charge | 90–100 km |
| Charging Time | 4–8 Hours |
| Gross Vehicle Weight | 713 kg |
| Front Suspension | 43MM Telescopic Hydraulic Shockers |
| Brake System | Both Drum Brake |
| Rear Suspension | Leaf Spring With Spring Shockers |
| Wheel Base | 1200 mm |
| Ground Clearance | 130 mm |
| Dimensions (LxWxH) | (2770 x 998 x 1720) MM |
| Key Feature | Central Locking & Fog Lights |
| Head Light | 12V Tube |
| Tyre | Front - 3.75 - 12 / Rear - 3.75 - 12 |
| Back Light | Unique Design with LED |
| Speedometer | Digital |
| Battery | Lead Acid / Lithium Ion |
| Wheel | Stylish Aluminium Alloy Wheel |
| Seats Capacity | 4+1 Passenger |
Motor
Type: BLDC 1000W / 1250W
Controller: Capacity 50A
Controller: Capacity 50A
Battery
Battery Type: Lead Acid / Lithium-ion
Charger: 18AMP / 25AMP
Charging Time: 4 to 8 Hours
Charger: 18AMP / 25AMP
Charging Time: 4 to 8 Hours
Performance
Speed: 25 KM/H (Economy Mode)
Range / Charge: 90 km to 100 km
Speedometer: Digital
Range / Charge: 90 km to 100 km
Speedometer: Digital
Chassis
Front Suspension: 43MM Telescopic Hydraulic Shockers
Rear Suspension: Leaf Spring with Spring Shockers
Brake System: Both Drum Brake
Tyre Size:
Front: 3.75 – 12
Rear: 3.75 – 12
Wheel Type: Stylish Aluminium Alloy Wheel
Rear Suspension: Leaf Spring with Spring Shockers
Brake System: Both Drum Brake
Tyre Size:
Front: 3.75 – 12
Rear: 3.75 – 12
Wheel Type: Stylish Aluminium Alloy Wheel
Dimensions
L × W × H: 2750 × 990 × 1790 MM
Wheel Base: 1200 MM
Ground Clearance: 140 MM
Gross Vehicle Weight: 584 Kgs
Loading Capacity: 150 Kg
Seating Capacity: 4+1 Passenger
Wheel Base: 1200 MM
Ground Clearance: 140 MM
Gross Vehicle Weight: 584 Kgs
Loading Capacity: 150 Kg
Seating Capacity: 4+1 Passenger
